Cy7 NHS ester

Catalog No.
A8109
Labeling of amino-groups in biomolecules.
Grouped product items
SizePriceStock Qty
5mg
$451.00
In stock
25mg
$935.00
In stock

Tel: +1-832-696-8203

Email: [email protected]

Worldwide Distributors

Background

Sulfo-Cy7 NHS ester is a sulfonated, hydrophilic and highly water soluble dye. This reagent allows prepare Cy7-labeled biomolecules, especially useful for the labeling of delicate proteins, and proteins prone to denaturation. Dye labeled molecules can be used for kinds of researches related experiments. Near infrared fluorescent imaging takes advantage of transparency of biological tissues at particular range of wavelengths. In live organisms, the method is non-destructive, and allows monitor distribution of various labeled molecules. Non-sulfonated Cy7 NHS ester soluble in organic phase is also available. For labeling proteins and peptides, no organic co-solvent is needed. In life science, the sulfonate groups make the Cy dyes soluble in water and also reduce fluorescence-quenching which can arise from dye–dye interactions.

In mice, Cy7-labeled RIG precursor solution and Cy7-labeled PIC micelles solution, was analyzed with an IVIS spectrum system. Administration of the Cy7-labeled RIG resulted in strong fluorescence signal in the mouth as compared with the orally administered Cy7-labeled PIC micelles solution [1].

Reference:
[1] Saita, M. ; Kaneko, J.; Sato, T.; Takahashi, S.; Takahashi, S.W.; Kawamata, R.; Sakurai, T.; Lee, M.-C.; Hamada, N.; Kimoto, K.; Nagasaki, Y. Novel antioxidative nanotherapeutics in a rat periodontitis model: Reactive oxygen species scavenging by redox injectable gel suppresses alveolar bone resorption. Biomaterials, 2016, 76, 292–301.

Product Citation

Chemical Properties

Storage24 months after receival at -20°C in the dark. Transportation: at room temperature for up to 3 weeks. Avoid prolonged exposure to light. Desiccate.
M.Wt827.94
FormulaC41H46N3NaO10S2
Solubilitygood in water, DMF, DMSO
Chemical Name(2E)-1-[6-(2,5-dioxopyrrolidin-1-yl)oxy-6-oxohexyl]-3,3-dimethyl-2-[(2E)-2-[3-[(E)-2-(1,3,3-trimethyl-5-sulfonatoindol-1-ium-2-yl)ethenyl]cyclohex-2-en-1-ylidene]ethylidene]indole-5-sulfonate
SDFDownload SDF
Canonical SMILESCC1(C2=C(C=CC(=C2)S(=O)(=O)[O-])[N+](=C1C=CC3=CC(=CC=C4C(C5=C(N4CCCCCC(=O)ON6C(=O)CCC6=O)C=CC(=C5)S(=O)(=O)[O-])(C)C)CCC3)C)C
Shipping ConditionEvaluation sample solution : ship with blue ice.All other available size: ship with RT , or blue ice upon request
General tipsFor obtaining a higher solubility , please warm the tube at 37 ℃ and shake it in the ultrasonic bath for a while.Stock solution can be stored below -20℃ for several months.

Spectral properties

Excitation max (nm) 750 Emission max (nm) 773
Extinction Coefficient (M-1cm-1) 240600 Quantum Yield 0.36
CF260 0.04 CF280 0.04

Quality Control

Quality Control & MSDS

View current batch:

Chemical structure

Cy7 NHS ester

Related Biological Data

Cy7 NHS ester

Related Biological Data

Cy7 NHS ester

Related Biological Data

Cy7 NHS ester
