Cy3.5 maleimide (non-sulfonated)

Catalog No.
A8264
Labeling of cysteine residues, as well as other thiolated molecules
Grouped product items
SizePriceStock Qty
5mg
$210.00
In stock
25mg
$410.00
In stock
For scientific research use only and should not be used for diagnostic or medical purposes.

Tel: +1-832-696-8203

Email: [email protected]

Worldwide Distributors

Background

Cy3.5 maleimide can be used for selective labeling of free sulfhydryl groups (e.g. cysteine residues in peptides, proteins and oligonucleotides). Before labeling, cystines should be prepared with reductant such as TCEP (tris-carboxyethylphosphine). The mono-reactive malemides is particularly good for the labeling of antibody, that’s because the dye molecules are located away from the antibody binding site and functioning of the labeled molecules can be protected.

Chemical Properties

Physical AppearanceA solid
StorageStore at -20°C
M.Wt715.32
Cas No.N/A
FormulaC44H47ClN4O3
Solubility≥71.5 mg/mL in DMSO; ≥28.5 mg/mL in EtOH with ultrasonic
Chemical Name3-(6-((2-(2,5-dioxo-2,5-dihydro-1H-pyrrol-1-yl)ethyl)amino)-6-oxohexyl)-1,1-dimethyl-2-((1E,3E)-3-(1,1,3-trimethyl-1H-benzo[e]indol-2(3H)-ylidene)prop-1-en-1-yl)-1H-benzo[e]indol-3-ium chloride
SDFDownload SDF
Canonical SMILESCN1C2=CC=C3C=CC=CC3=C2C(C)(C)/C1=C\C=C\C4=[N+](CCCCCC(NCCN5C(C=CC5=O)=O)=O)C6=CC=C(C=CC=C7)C7=C6C4(C)C.[Cl-]
Shipping ConditionSmall Molecules with Blue Ice, Modified Nucleotides with Dry Ice.
General tips We do not recommend long-term storage for the solution, please use it up soon.

Spectral properties

Excitation max (nm) 591 Emission max (nm) 604
Extinction Coefficient (M-1cm-1) 116000 Quantum Yield 0.35
CF260 0.29 CF280 0.22

Quality Control

Quality Control & MSDS

View current batch:

Chemical structure

 Cy3.5 maleimide (non-sulfonated)
